A double-butted 4130 CrMo steel frame and fork are designed to be comfortable on rough roads and handle fully loaded-touring and bikepacking. We've included six bottle mounts, rack and fender eyelets, lowrider fork mounts, generous tire clearance, and disc brakes to set you up for all conditions and all terrain.

Don't be fooled; that classic frame material doesn't mean low-tech. We've used biometric fit data to offer five different frame sizes, with size-matched 650b or 700C wheels to suit riders between 4'11 perfectly" – 6'4". A high front end creates all-day comfort and heads-up visibility; off-road-ready geometry means you won't skip a beat when you head off the asphalt and explore Beyond Road.

New for '24, the Four Corners 2 takes all the elements that make the Four Corners fantastic and adds a Series 3 double-butted CrMo frameset, a simpler, wide-range SRAM 1x12 speed Apex drivetrain, and matching, powerful Apex 1 hydraulic disc brakes. The rubber meets the road/path/trail with wider, 44mm Vee Tire Quickstyx tubeless-compatible tires, and the frame can accept tires up to 50mm wide.

Specifications

• Frame

  Series 3 Double Butted CrMo, Size-Specific Wheels (XS, S = 650B, M, L, XL = 700C) , Biometric Geometry, Fender and Rack Mounts, 142x12mm Thru-Axle, Flat Mount 160 Disc Mount, Plentiful Gear Mounts

• Fork

  Series 3 CrMo, 100x12mm Thru-Axle, Flat Mount 160 Disc Mount, Fender, Rack, and Bottle Cage Eyelets

• Rims

  Marin Aluminum Double Wall, 25mm Inner, Disc Specific, Tubeless-Compatible

• Hub Rear

  Forged Aluminum Alloy, Disc, 32H

• Hub Front

  Forged Aluminum Alloy, Disc, 32H

• Spokes

  14g Black Stainless Steel

• Tires

  Vee Tire Co., Quickstyx, 650/700x45, Tubeless-Compatible

• Derailleur Rear

  SRAM Apex 1 12-Speed

• Derailleur Front

  -

• Shift Lever

  SRAM Apex 1 1x12-Speed

• Crankset

  SRAM Apex 1, 40T

• Bottom Bracket

  SRAM DUB BSA

• Chain

  SRAM NX

• Cassette

  SRAM CS-XG-1275, 10-52T

• Brakes Front

  SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor

• Brakes Rear

  SRAM Apex 1 Flat-Mount Hydraulic Disc, 160mm Rotor

• Brake Levers

  SRAM Apex 1 Hydraulic Disc

• Handlebar

  Marin Butted Alloy, Compact 16º Flared Drop

• Stem

  Marin 3D Forged Alloy

• Grips

  Marin Comfort Tape

• Headset

  FSA No.42/ACB

• Seatpost

  Marin Alloy, 27.2mm

• Saddle

  Marin Beyond Road Concept

• Pedals

  Marin Oso OEM Nylon Platform

• Extras

  Bolt-On Thru-Axles F & R
